Raycus Laser Source 2000w Description
As the most famous laser brand in China, it provides many solutions, from pulse laser to fiber laser, rich types and various powers ensure the application of many terminal products. From 20W to 10kW, the product level can meet the application of various needs such as high power cutting machines. Moreover, the working time of 100000 hours ensures the service life of the product in order to achieve better cost savings
Raycus Laser Source 2000w Applications
1.Precision Cutting
2.Metal Welding
3.Sheet Metal Piercing
4.Metal Carving
5.Surface Treatment
6.3D Printing/Rapid Prototyping
7. Laser cleaning
Raycus Laser Source 2000w Features
Specifications
|
Model |
C1000/C1500/ C2000 |
|
Optical Characteristics |
|
|
Nominal Output Power(W) |
1000/1500/2000 |
|
OperationMode |
CW |
|
Polarization State |
Random |
|
Output Power Tunability(%) |
10~100 |
|
Emission Wavelength(nm) |
1080土5 |
|
Output Power Instability |
士1.5 |
|
Modulation Frequency(Hz) |
50~50,000 |
|
Red Guide Laser Power(m W) |
0.1-1 |
|
Optical Output Characteristics of QBH head |
Beam Quality |
|
Control Mode |
RS-232/AD/Ethernet |
|
RS-232/AD/Ethernet |
Other Characteristics |
|
Dimensions(W>H×D) |
485×237×763/520×620×986(include.handles) |
