Backpack laser rust cleaning on metal surface lazer paint remover laser oxide derusting machine 20w 50w100w
Products Description
Machine introduction
QA-LC20B 20W Backpack Laser Cleaning Paint Remover is a backpack type laser rust removal machine for cleaning historical sculpture. Free to work outside like on bridge and wall.
There is oxidation and corrosion when metals meet oxygen and water vapor in air. 20W Backpack Laser Cleaning Paint Remover will greatly damage the metal workpiece and the rust will spread from outside to inside and become worse and worse as time goes on, until the whole workpiece is totally corrupted. So rust removal is extremely important. Laser rust removal uses not chemical agents or mechanical polishing, so it is faster and safer. It has advantages of higher efficiency, high automation and no subsequent processing work, lower labor intensity and lower cost.
20W Backpack Laser Cleaning Paint Remover is a new generation of industrial surface cleaning laser system. It adopts the advanced laser source, laser optical scanners and control system to meet the requirements of metal surface cleaning process.
Products Parameters
|
Model |
QA-LC20B |
QA-LC50B |
QA-LC100B |
|
Laser source |
Fiber |
Fiber |
Fiber |
|
Laser Power |
20W |
50W |
100W |
|
Fiber cable length |
3 M |
3 M |
5 M |
|
Laser Wavelength |
1064nm |
1060nm |
1064nm |
|
Pulse Energy |
0.6 mJ |
1 mJ |
1.5 mJ |
|
Pulse frequency |
1-2000KHz |
1-4000KHz |
1-4000KHz |
|
Scanning speed |
0-7000mm/s |
0-7000mm/s |
0-7000mm/s |
|
Cooling |
Air cooling |
Air cooling |
Air cooling |
|
Dimension |
300*160*450 mm |
400*118*460 |
350*180*450 mm |
|
Weight |
7Kg |
8.5Kg |
10Kg |
|
Beam width |
10-70mm |
10-100mm |
10-175mm |
|
Optional |
Manual |
Manual/Auto |
Manual |
|
Temperature |
5-40 ℃ |
5-40 ℃ |
5-40 ℃ |
|
Voltage |
Single Phase 220V, 50/60HZ |
Single Phase AC 220V,50/60HZ |
Single Phase AC 220V, 50/60HZ |
comparison with traditional clean methods
| Comparison | Laser Cleaning | Chemical Cleaning | Mechanical Grinding | Dry ice cleaning |
| Washing Method | non-contact cleaning | contact cleaning | Abrasive contact cleaning | non-contact cleaning |
| Harm to base material | None | Yes | Yes | None |
| Washing Efficiency | High | Low | Low | Mid. |
| Consumable | Power | Chemical Detergent | Abrasive paper, grinder, abrasive stone | Dry Ice |
| Washing result | Very good, very clear | Medium, uneven | Medium, uneven | Good, uneven |
| Precision Washing | Accuracy controllable. High precision | Uncontrollable, low precision. | Uncontrollable, medium precision. | Uncontrollable, poor precision. |
| Safety/Environment | No pollution | Chemical pollution | Dust pollution | No pollution |
| Operation | Easy to operate, portable or automation optional. | Complicated process, higher technical requirement of the operator. Pollution prevention measures required. | Need more time & manpower. Pollution prevention measures required. | Easy to operate, portable or automatic. |
| Investment | High investment on machine. But no consumable, low maintenance cost | Low investment on machine. But expensive consumables | Medium investment on machine. High man-power cost. | Medium investment on machine. High consumable cost. |
application
Widely used for the surface laser degreasing, laser paint removal, laser removal of zinc, laser film removal, laser cleaning, such as coating, etc
This type is especially design for culture relics.
FAQ
1. What is a backpack laser cleaning machine?
A backpack laser cleaning machine is a portable device that uses laser technology to clean various surfaces, including metal, stone, and plastic.
2. What are the advantages of using a backpack laser cleaning machine?
The backpack laser cleaning machine offers several advantages, including portability, ease of use, and precise cleaning without causing any damage, making it suitable for various applications.
3. What surfaces can the backpack laser cleaning machine clean?
The backpack laser cleaning machine can clean various surfaces, including rust, paint, oil, and other contaminants. It is suitable for cleaning metal, stone, and plastic surfaces.
4. How does the backpack laser cleaning machine work?
The backpack laser cleaning machine works by emitting a laser beam that removes contaminants and leaves behind a clean surface. It works by ablating the surface, causing the contamination to evaporate without causing any damage.
5. Is the backpack laser cleaning machine safe to use?
Yes, the backpack laser cleaning machine is safe to use. It does not generate any hazardous waste or emit harmful fumes, making it an eco-friendly option for cleaning surfaces.
6. Can the backpack laser cleaning machine replace traditional cleaning methods?
The backpack laser cleaning machine can complement traditional cleaning methods, especially in applications where traditional methods are not suitable. Its portability and ability to clean precise areas make it a valuable tool for various industries.
