Products Description
Raycus 1500w laser source
The Raycus 1500W fiber continuous laser is a state-of-the-art laser system that delivers high-quality performance for a wide range of industrial applications. With its advanced technology and powerful output, this laser is perfect for manufacturing, cutting, welding, and marking on metals and non-metals alike.
The Raycus fiber continuous laser features a robust design, ensuring that it will provide reliable and consistent operation in even the most demanding industrial environments. Its high-power output allows for fast and precise cutting and welding, making it an ideal choice for precision manufacturing and fabrication.
This laser is also incredibly energy-efficient, with a low operating cost that translates to significant savings for businesses of all sizes. It is easy to operate and maintain, with a simple user interface that allows for quick and easy tuning and adjustments.
Applications
Precision Cutting
Metal Welding
Sheet Metal Piercing
Metal Carving
Surface Treatment
3D Printing/Rapid Prototyping
Specifications
Models | RFL-C1500 |
Nominal Power | 1500w |
Mode of Operation | CW/Modulated |
Power Tunability | 10 to 100 % |
Wavelength | 1080 ± 10 nm |
Power Stability | ±1.5 % |
Laser Beam Quality | 5-6M²(50μm) |
Modulation Frequency | 50~20kHz |
Output power instability | ±1.5% |
Red Laser | Yes |
FIBER DELIVERY SYSTEM | |
Interface | QBH (customizable) |
Length | 20 m standard, other lengths optional |
Diameter | 50 μm |
Polarization | Random |
ELECTRICAL RATINGS | |
Supply Voltage | 220±10%,50/60Hz |
Control mode | external RS232, external AD, super terminal |
OTHER SPECIFICATIONS | |
Operating Temperature | +10 to +40 ℃ |
Storage Temperature | -10 to +60 ℃ |
Humidity | 10 to 85 % |
Cooling Method | Water Cooling |
Dimension | 410*610*150 mm |
Weight | 40 kg |
